  • Availability: in stock Many in stock Out of stock You can purchase this product but it's out of stock

24" Dual Heads Array High Speed A3+ DTG Printer 3360

$7,899.00
  • Barcode:

Overview


DTG printer means direct to garment printer, it enables individuals to customize textiles freely, such as clothing and pillows, which can be applied in many fields.
The more the cotton content of the fabric contains, the firmer the printing color on fabric lasts and the higher of the washability.The advantage of this new printing teconology on fabric is that the fabric is more breathable without feeling of film.

Features

  • Automatic and Moisturzing System – prolong print head service time.
  • White Ink Automatic Circulation – minimize printer head clogs and greatly extend print head lifetime.
  • Automatic Height Adjustment- Humanized design, automatically adapt to different height printing material, higher efficiency.
  • High quality Screw Slide Track – Compared to traditional belt conveyance, printing position is more accurate.
High Quality Screw Slide Track

Compared to traditional belt conveyance, printing position is more accurate .

Automatic Wiping and Moisturizing System

Automatic wash the printhead when the machine is turned on and keep it wet when turned off to protect printhead blocking when it's not used and after printing

Ink Circulation, Prevent Nozzle Clogging

The ink circulation system is our patent technology, the continuous circulation system effectively prevent the nozzle from clogging, thus extend print head lifetime 50% compared to traditional printers.

Key Specification

Print Head Model TX800*2 XP600*2
Ink Supply CMYKWW(12 Color) CMYKWW(12 Color)
Printing Head 3-5 m2/ H, 8 pass 3-5 m2/ H, 8 pass
Printing Effect Better Better
Embossing Effect Support Support

Technical Support



Printing Step



What’s In The Box

  • DTG Printer 3360
  • Garment Fixture(customer purchase)
  • Full Set of Initial Textile Ink  (CMYKW 5*100ml)
  • Clothing pretreatment liquid 1*100ml
  • Ink cleaner 1*100ml
  • Nozzle protection fluid 1*50ml
  • Steel Ruler/Water Tank/4 Spare Ink Sac/Insurance
  • 6*1.2m Tubes/1.5m Wire/3pcs Syringe
  • Magnet Paper/Sticky Tape/Double Side Tape/Dust-Free Cloth

Printing Sample


Dispatch Procedure


Our Certificates


Shipment




Feedback





Specification

Model
A3+ 3360 DTG
Print head
XP600*2 OR TX800*2
Resolution
5760*1440DPI
Print width
330mm
Print speed
3-5 m2/ H, 8 pass
software
included
Ink consumption
1m2 / 20ml
OS
WindowXP、7、10
Ink supply mode
12 colors (CMYKWW 6-color/print head)
Color scheme
CMYK+WWWWWW
White ink output
support / white, color print at the same time
Varnish print
none
White ink mixing
own
Relief printing
own
Voltage/plug
According to the country
Package size
L1040*W900*L900mm
Nozzle protection
The ink pad maintenance fluid is anti-cloggingv
Printer size
690*700*550mm
Print media
Leather/textile, etc.
Net weight/Gross weight
70KG/118KG
Warranty
Three-year warranty [Parts in contact with ink (or parts damaged by ink) are not guaranteed]
Outer packaging
Export wooden box (with forklift feet) + foam

Shipping Time

  • Usually it takes 7 to 14 business days to arrive.
  • Our default shipment method is DHL Express
  • If you purchase ink, powder and other consumables together with the machine, the machine will be transported separately from the liquid and powder according to the transportation policy, so the delivery time is not exactly the same.
Shipping Fee

  • FREE Shipping on all items for most countries.
  • Some remote countries and regions such as Africa and Latin America need to make up part of the freight. The specific standard is subject to the shipping fee displayed at checkout.
Tax

  • Import tax and VAT are not included in the price, except for US and EU clients - we have local warehouse, customer only need to pay VAT, import tax are prepaid.
  • We’ll prepare the documents to assist on the custom clearance. More questions, please contact our sales.
Package

  • Preassembled: your printer's stand, printheads, and ink system are all assembled here by our technicians and then repackaged for freight shipment.
  • The machine is first packaged with transparent plastic film. Then put it into a wooden box and fill the gap with foam to better protect the machine.


1.What’s your technical support?
We provide after-sales service throughout the day, online technical guidance on working days, 3 years warranty. If you have any difficulties after receiving the goods, you can contact our customer service, and we will connect you with professional technical personnel.

2. Are you manufacturer ?
Yes, we are Procolored Manufacturer, our factory has two floors production work shops, three production line, and four mainly oversea warehouse in US/UK/ES/RU to produce and our promote our printer.

3. What is your warranty?
All uv printer , dtf printer and dtg printer are guaranteed for 3 years starting from the date of shipment, but the parts passed by the ink ( including print head , ink pump , cartridges , ink motor etc ) are NOT included in this clause.

4. How can I adjust the print height ?
Procolored UV/DTG Flatbed printer coming with infrared sensor, so the printer can detect the height of printing objects automatically.

5. Where can I buy the spare parts and inks?
We provide spare parts and inks, you can buy from directly or through other suppliers in your local market.

6. What about daily maintenance of the printer?
About maintenance, we suggest to power on the printer once a day.If you don't use the printer more than 3 days, please clean the print head with cleaning liquid and put it in the protective cartridges which are specially used to protect print head.

7. Does the printer support white and color print at the same time?
Yes, our printers are support white and color print in one piece.

8. How to install software after I received the machine ?
There is a software usage method for your reference, the installation method can be reviewed in the user manual. Or please contact us, our after-sales engineers will help to solve the problem.

9. What should I do when I don’t really know how to setting the printer parameters?
Please contact us for technical help and do not artificial modification.We always provide on-line technology support if there still have any issues.
